Mess-Technik Blatter AG

Since 1990, Mess-Technik Blatter AG has been known as a modern and competent company for calibrations and testing activities in the field of length and torque .

Our service

Expertise
Thanks to our highly trained and qualified staff and the use of the latest technology, we perform all tasks relating to normative requirements for test equipment monitoring with a high degree of expertise and professionalism.

Calibration
's calibrations meet all requirements for ISO 9001, ISO13485, 21 CFR Part 820, and ISO/TS 16949 certification. Benefit from our extensive experience with various industry-specific requirements.

Test equipment management
To ensure that we meet the relevant certification requirements, we work with our specially developed and validated management software, guarantee four-language support, and ensure that all relevant data and information can be accessed and queried thanks to web integration.

Personnel
Our highly trained measurement technicians all have basic technical training and several years of experience in the field of measurement technology. In addition, they keep up to date with the latest technology through ongoing theoretical and technical training.



Calibration
Mess-Technik Blatter AG is accredited under accreditation no. SCS No. 0030 in accordance with EN ISO / IEC 17025.
Our range of services includes accredited calibrations as well as some non-accredited calibrations. A detailed overview can be found in the following list.

• Caliper gauges / depth gauges (SCS)
  Our calibration instruction MTB/1 A is based on standard DIN 862 with a best possible measurement uncertainty of:
  (15+5*L) µm, L in m

• Micrometers (SCS)
  Our calibration instruction MTB/2 A based on standard DIN 863 Part 1 with a best possible measurement uncertainty of: 1.5 µm

• Internal micrometers (SCS)
  Our calibration instruction MTB/3 B based on standard DIN 863 Part 4 with a best possible measurement uncertainty of: (1.5+4*L) µm, L in m

• Depth micrometers / built-in micrometers (SCS)
  Our calibration instruction MTB/4 A based on standard DIN 863 Part 2 with a best possible measurement uncertainty of: (2+3*L) µm, L in m

• Angle gauges (SCS)
  Our calibration instruction MTB/5 A based on standard VDI 2618 Sheet 12 with a best possible measurement uncertainty of: 1′ 30″

• Dial gauges / precision indicators (SCS)
  Our calibration instruction MTB/6 C based on standard DIN 878 / DIN 879 with a best possible measurement uncertainty of: 0.5 µm

• Probe lever gauges (SCS)
  Our calibration instruction MTB/7 A based on standard DIN 2270 with a best possible measurement uncertainty of:
  0.5 µm

• Limit gauges / measuring bolts / test discs Thread measuring wires (SCS)
  Our calibration instruction MTB/8 B based on standard DIN ISO 286 with a best possible measurement uncertainty of: 0.25 µm for measuring wires 0.40 µm for other cylindrical test equipment and test discs

• Thread limit plug gauges (SCS)
  Our calibration instruction MTB/9 C based on standard DIN 13, ANSI/ASME, B.S.84, BS919 with a best possible measurement uncertainty of: (3+1.5*L) µm, L in m

• Thread gauges (SCS)
  Our calibration instruction MTB/10 B based on standards DIN 13, ANSI/ASME, B.S.84, BS919 with a best possible measurement uncertainty of: (3+1.5*L) µm, L in m

• Throat gauges (SCS)
  Our calibration instruction MTB/11 B based on standard DIN ISO 286 with a best possible measurement uncertainty of: (0.6+1.5*L) µm, L in m

• Quick gauges / quick measuring devices (SCS)
  Our calibration instruction MTB/12 A based on standard DIN ISO 286 with a best possible measurement uncertainty of:
  15 µm

• Rulers (SCS)
  Our calibration instruction MTB/13 A based on DIN 874 with a best possible measurement uncertainty of:
  (1.5+0.5*L) μm + A*0.02 L in m (A=display in μm)

• Angles / hair angles / centering angles (SCS)
  Our calibration instruction MTB/14 A based on standard DIN 875 with a best possible measurement uncertainty of:
  (1.4+0.5*L) μm + A*0.02 L in m (A=display in μm)

• Gauge rings (SCS)
  Our calibration instruction MTB/15 B with a best possible measurement uncertainty of: 0.3 µm roundness 0.10 µm

• Parallel gauge blocks / setting gauge blocks (SCS)
  Our calibration instruction MTB/16 C based on standard DIN EN ISO 3650 with a best possible measurement uncertainty of: (0.06+0.7*L) µm, L in m

• Marking and height measuring instruments (SCS)
  Our calibration instruction MTB/17 B with a best possible measurement uncertainty of: (1.5+2.5*L) µm, L in m

• Tape measures / folding rules / metal rulers
  Our calibration instruction MTB/18 A with a best possible measurement uncertainty of: 0.2mm

• Spirit levels / inclinometers
  Our calibration instruction MTB/19 A with a best possible measurement uncertainty of: 0.3 divisions

• Flat glass
  Our calibration instruction MTB/20 A with a best possible measurement uncertainty of: 0.15 µm

• Form measurements (gauge pins, gauge rings, and measuring columns) (SCS)
  Our calibration instruction MTB/21 B with a best possible measurement uncertainty of: 0.1 µm

• Flatness on hard stone plates (SCS)
  Our calibration instruction MTB/22 C based on standard DIN 876 Part 1 with a best possible measurement uncertainty of: (0.5+0.5*L) µm, L in m

• Optical measurements (measuring projector)
  Our calibration instruction MTB/23 A with a best possible measurement uncertainty of: 5µm

• Sphere (SCS)
  Our calibration instruction MTB/24 A

• Torque wrench / torque screwdriver (fixed) (SCS)
  Our calibration instruction MTB/40 C based on standard DIN 6789 with a best possible measurement uncertainty of: 1%

• Torque wrench / torque screwdriver (SCS)
  Our calibration instruction MTB/41 C based on standard DIN 6789 with a best possible measurement uncertainty of: 1%

• Transducers / Display devices (SCS)
  Our calibration instruction MTB/42 C based on standard DIN 6789 with a best possible measurement uncertainty of: 0.4%

• Measuring probes / display devices
  Our calibration instruction MTB/43 A based on standard DIN 878 / DIN 879 with a best possible measurement uncertainty of: 0.5 µm

• Spring balances / force measuring devices (SCS)
  Our calibration instruction MTB/50 A with a best possible measurement uncertainty of: 5%

• Scales / Weights
  Our calibration instruction MTB/51 A with a best possible measurement uncertainty of: 0.2%

• General visual functional test
  Our calibration instruction MTB/60 A

• External calibration / calibration centers
  Our calibration instruction MTB/60 A

-------

Calipers, depth gauges, calipers, depth gauges, micrometers, internal micrometers with 3-line contact, internal micrometers with 2-point contact, depth micrometers, built-in micrometers, angle gauges, dial gauges, electronic measuring probes, feeler gauges, limit gauges, individual gauges / test discs, gauge set, Test gauge for micrometers, individual test pins, test pin sets, thread gauges, thread gauges/reject gauges, thread limit gauges, thread gauges, limit rake gauges, internal measuring devices/quick-action gauges, rulers/hairline rulers, angles (flat and stop angles), hair angle, hard stone angle, toolmaker's angle, gauge rings, parallel end gauges, setting end gauges, height gauges, marking gauges, steel rulers / tape measures / folding rulers, inclinometers / spirit levels, flat glass, test plates / hard stone plates, optical measurement, torque wrenches / screwdrivers, precision torque testers, torque testers / torque load cells, spring balances, force gauges
